EG4 LL Lithium Battery (V2) | 24V 200AH | Server Rack Battery

$1,499.95
$1,329.00
$259.57 / Kilowatt-hour

SKU:
1511042
Nominal Voltage:
25.6V
Nominal Capacity:
200Ah
Kilowatt-hour(s):
5.12kWh
Dimensions:
17.7" x 19.3" x 6.1"
Design Life:
+15 Years at 80% DoD
Communications:
RS485/CAN: Schneider, Sol-Ark, Victron, Growatt, EG4
Spec Sheet:
Manual:
BMS Software:

EG4 LL Lithium Battery (V2) | 24V 200AH | Server Rack Battery

Upgraded EG4-LL (Lifetime Lithium) Lithium Iron Phosphate battery 25.6V (24V) 5.12kWh with 200A internal BMS, based on the same subset features of the previous industry renowned EG4-LL Battery. Fully Compatible with Previous EG4-LL Model (See below).

Composed of (16) UL listed prismatic 3.2V cells which have been tested at 7,000 deep discharge cycles to 80% DoD - fully charge and discharge this battery daily for over 15 years without issue. Reliable and rigorously tested, with a 99% operating efficiency. Includes an LCD screen to quickly view your batteries' most important information, but now features Selectable closed-loop inverter communications including Schneider, Solark, Victron, Growatt, and EG4! A simple plug-and-play interface that has all the essentials built in for easy setup.

EG4 Lifetime Lithium, Best In Class Solar Rack Battery

  • Rated for 7000 deep charge & discharge cycles
    • 15-year life with 80% depth of discharge daily, designed for up to 20-year life
  • Tier One, A+ Cell Composition, 99% Efficiency LiFePo4 16-Cell Pack
  • #1 Energy Density Server Rack Battery Form Factor
  • Dual Onboard automatic fire arrestors
    • Failsafe operation in high-risk environments and to protect against rare
      hardware failure on high voltage solar charge controllers!
  • Parallel up to 16 batteries
    • Get the most power possible! Up to 81.9kWh while maintaining BMS
      communications!
  • Have existing V1 EG4-LL Batteries? Enable expanded communication for existing V1 EG4-LL Battery Banks by using a new V2 EG4-LL Battery as your master battery.

Advanced Configurability

  • On-board LCD Screen
  • PC Monitoring Software
  • Lifetime firmware updates

Reliability & Safety Testing

  • Dual On-board Fire Arrestors
  • Environmentally Friendly & Lead-Free
  • Design Optimized and Tested by EG4's R&D Solar Laboratory. In-House & Texas Based
  • 10-Year Warranty Supported and serviced out of Texas

Included:
(1) 1 foot RS485 Communication Cable and (1) Set of Parallel Cables per battery
(1) RS485 USB Battery Comm Cable PER (6) BATTERIES (shipped separately)

Nominal Voltage:
25.6V
Nominal Capacity:
200Ah
Kilowatt-hour(s):
5.12kWh
Dimensions:
17.7" x 19.3" x 6.1"
Design Life:
+15 Years at 80% DoD
Communications:
RS485/CAN: Schneider, Sol-Ark, Victron, Growatt, EG4
Spec Sheet:
Manual:
BMS Software:
10-Year Warranty
Customer Reviews
4.9 Based on 31 Reviews
5 ★
94%
29
4 ★
6%
2
3 ★
0%
0
2 ★
0%
0
1 ★
0%
0
Customer Photos
Write a Review Ask a Question

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

Filter Reviews:
WP
05/17/2025
Wilderich P.
United States

Battery test 48v 100Ah

I m happy with this product every works well

Signature Solar EG4 LL Lithium Battery (V2) | 24V 200AH | Server Rack Battery ReviewSignature Solar EG4 LL Lithium Battery (V2) | 24V 200AH | Server Rack Battery ReviewSignature Solar EG4 LL Lithium Battery (V2) | 24V 200AH | Server Rack Battery ReviewSignature Solar EG4 LL Lithium Battery (V2) | 24V 200AH | Server Rack Battery Review
D
03/17/2025
Dwight
United States

LL-S review

I received an LL-S as a warranty upgrade. my original LL-2V had a bad cell and these had just come out..... I love everything about it.... the touch screen lets me see the cells are balancing. I do disconnect my panels once a month and let the battery cycle down as living in southern Arizona I'm never under 50%. battery cycles down and shuts off at 19% each month no problem..... glad I paid a little extra and got the display

DG
03/16/2025
David G.
United States

Very well designed

As a technician I really like the design of the rack and easy way to assemble the batteries.

Signature Solar EG4 LL Lithium Battery (V2) | 24V 200AH | Server Rack Battery Review
AL
02/13/2025
Alan L.
United States

Good batteries

The EG4 LL-s batteries work well so far.

AD
02/07/2025
Andrew D.
United States

Good batteries!

Excellent batteries for a decent price!
