Staubli MC4-Evo 2 Branch Plug and Socket


Spec Sheet:
Assembly Instructions:

1500Vdc Rated Branch Parallel Connectors

Branch Plug MC4-Evo 2 PV-AZS4 and PV-AZB4 connectors use for connecting simple parallel or serial parallel connection of PV-modules. MC4s are often viewed as the standard connector in the solar energy industry.

• Plug-and-play: no crimping or torqueing necessary
• Versatility and compact dimensions
• Mating compatibility with original MC4 and MC4-Evo 2 cable connectors
• DC 1500 V according to IEC 62852 and UL 6703
• Resistance to salt mist spray
• Proven MULTILAM Technology with high long-term stability which ensures consistently low performance loss throughout the entire service life of the connector
